New Fabric loading design. Easy loading material.
Titled body design. Easy to operate and maintain.
Thread brake detector.
Pneumatic air thread cutting system.
Operated using high quality sealed bearings that do not need lubrication.
Adjustable presser foot lifting mechanism enables you to quilt a broad range of material thickness.
Emergency safety devices.
Improved quilting software control system allows more precise and stable quilting operations.
CAD pattern drawing pattern system allows you to create your own design.
Machine comes with 100-300 design patterns.
Error problem detection system.
Pattern compensation.

Auto adjustable feed rollers allow operator to adjust
various type of thickness.
Fabric holder transport block ensures that machine operates with more stability and less noise.
Sealed fabric rollers allow better control of design pattern.
High speed machine operation and stable control.
Heavy duty tracking system for feed in and feed out material.

Technical Specification:

Size (length*width*height)	5100X1500X2000(mm)
Weight	5000kg
Quilt width	2450mm
Rotation speed	600-1200RPM
Production speed	80-280m/h
Needle size	130/21  140/22  160/23  180/24
Needle arrangement	(50.8 , 76.2 , 127)    (76.2, 76.2 , 152.4)
Max horizonal movement	450mm
Needle space	25.4mm
Voltage	380V/220V  50HZ/60HZ
Stitch size	2-7 mm
Power	10KW
Quilting thickness	≤80mm

Feature Icon:

New generation control system	A high powered fast speed controlled servo motor	New hopper balance system	Pneumatic system for pressing foams

Applications:
Mattress Comforter Clothing Handbag Glove Sleeping bag All bed equipment of pattern.
